Seeed Studio is now shipping the J101 and J202 carrier boards for the Jetson NX form factor modules. This includes the Jetson Nano, Nano 2GB, Xavier NX and TX2 NX. The Seeed carrier boards are the same physical dimensions as the NVIDIA developer kits.

The J101 is priced at $69 USD, and the J202 is priced at $139.

The Seeed carrier boards are for use with NVIDIA Jetson production modules. The production modules replace the micro SD card of the developer module with eMMC. The J101 adds a micro SD card slot to the carrier board, and is similar to the Jetson Nano 2GB Dev Kit carrier board. The J202 is very similar to the feature set of the NVIDIA Jetson Xavier NX Dev Kit, with a few extra niceties added.

Here’s some pics (click to expand):

Comparison among NVIDIA Dev Kits and reComputer carrier boards

Feature Jetson Nano Dev Kit(B01) reComputer J101 Jetson Xavier NX Dev Kit reComputer J202
Module Compatibility Jetson Nano 4GB (non-production version) Jetson Nano series Jetson Xavier NX 8GB (non-production version) Jetson™ Nano/Xavier NX/TX2 NX
PCB Size / Overall Size 100mm*80mm 100mm*80mm 100mm*80mm 100mm*80mm
Display 1* HDMI+1* DP 1* HDMI 1* HDMI+1* DP 1* HDMI+1* DP
CSI Camera 2* CSI 2* CSI 2* CSI 2* CSI
Ethernet 1* Gigabit Ethernet (10/100/1000M) 1* Gigabit Ethernet (10/100/1000M) 1* Gigabit Ethernet (10/100/1000M) 1* Gigabit Ethernet (10/100/1000M)
USB 4* USB 3.0 Type-A (5Gbps); 1* USB Type-C (Power In); 4* USB 3.1 Type-A  (10Gbps); 4* USB 3.1 Type-A  (10Gbps for NX, 5Gbps for Nano);
1* USB 3.0 Type-A  (5 Gbps);
2* USB 2.0 Type-A;
1* USB Micro B (Device mode) 1* USB Type-C (Device mode) 1* USB Micro B (Device mode) 1* USB Type-C (Device mode)
M.2 Key M 1* M.2 Key M 1* M.2 Key M
Micro SD card 1* Micro SD card slot (48MHz CLK Frequency)
M.2 Key E 1* M.2 Key E 1*M.2 Key E 1* M.2 Key E 1* M.2 Key E
FAN 1* Fan Connector 1* Fan Connector 1* Fan Connector 1* Fan Connector
CAN (reserved) 1* CAN
Multifunctional port 1* 40-Pin 1* 40-Pin 1* 40-Pin 1* 40-Pin
1* 12-PIn 1* 12-PIn 1* 12-PIn 1* 12-PIn
RTC RTC socket(reserved) RTC 2-pin RTC socket(reserved) RTC 2-pin
RTC socket(reserved) RTC socket
Power supply 5V/4A(Barrel Jack 5.5/2.5mm)
5V/2A(USB Micro B)
5V/3A(USB Type C) 19V/4.74A(Barrel Jack 5.5/2.5mm) 12V/5A(Barrel Jack 5.5/2.1mm)
Not included Not included Power Cord provided only Power Cord provided only

These carrier boards are also offered in complete systems in different configurations, such as the reComputer we reviewed here:
